26
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
Insert the 4 1/2” U-Bolt (AOU) through the upper part of the opening on the
backside of the "ACKBOARD!*) as shown.
SEC
3.4
Connect the Rim (ALX) and 0LASTIC'UARD!,$ to the "ACKBOARD!*) with the
hardware shown. Thread the v*AM.UTS!!6 all the way down on the
4 1/2” U-Bolt (AOU). On the underside of the Backboard, place .38” x 1” Steel
Spacers (ACS) onto the vXv4AP"OLTS!"', and secure the 5/16”
.YLOCK&LANGE.UTS!"+onto the Tap Bolts.
SEC
3.5
1/2”
ACS (x2)
ABK (x2)
AAV (x2)
!*)
AOU
ABK
Underside View
ABK
ACS
ALD
AAV
AAV
ALX
!*)
!"'
