Lightware HDMI-3D-OPT-TX210RAK

USB
USB connector ............................................................................................ USB mini B type
USB 2.0 compliance ....................................................................................................... Yes
Optical
Fiber type ............................... 50/125 SC Multi-mode (preferred), 62.5/125 SC Multi-mode
Laser wavelengths .............................................. High speed lanes: 778; 800; 825; 850 nm
.......................................................................................................Low speed lane: 980 nm
Laser class specication ........................................................................................ Class 3R
11.2. Input/output port numbering
The following tables contain the input and output ports with their ID numbers which shall be
used when protocol command sending or in Lightware Device Controller.
HDMI-3D-OPT-TX210A and HDMI-3D-OPT-TX210RAK
Port name
Video port nr.
(LW2 / LW3)
Emulated EDID
memory
Audio port nr.
(LW2 / LW3)
HDMI in I1 E1 I1
Audio1 in - - I2
Audio2 in - - I3
Link out O1 - O1
Local out O2 - O2
SW4-OPT-TX240RAK
Port name
Video port nr.
(LW2 / LW3)
Emulated EDID
memory
Audio port nr.
(LW2 / LW3)
DP in I1 E1 I1
HDMI1 in I2 E2 I2
HDMI2 in I3 E3 I3
DVI-D in I4 E4 I4
Audio1 in - - I5
Audio2 in - - I6
Link out O1 - O1
Local out O2 - O2
HDMI-3D-OPT-TX200 series
User’s manual
Appendix Page 101 / 106
