Lightware HDMI-3D-OPT-TX210RAK

Gain
Command format: SET●/MEDIA/AUDIO/<I
n
>.Gain=<level>
Response format: pw●/MEDIA/AUDIO/<I
n
>.Gain=<level>
Parameters:
<level> Sets the input gain between -9 dB and 6 dB in step of 3 dB. The
value is rounded down if necessary to match the step value.
Example:
˃ SET /MEDIA/AUDIO/I5.Gain=3
˂ pw /MEDIA/AUDIO/I5.Balance=3
8.7. RS-232 port conguration
8.7.1. Protocol setting
Command format: SET●/MEDIA/UART/<P
n
>.ControlProtocol=0|1
Response format: pw●/MEDIA/UART/<P
n
>.ControlProtocol=0|1
Parameters:
.ControlProtocol 0 1
RS-232 protocol mode LW2 LW3
Example:
˃ SET /MEDIA/UART/P2.ControlProtocol=1
˂ pw /MEDIA/UART/P2.ControlProtocol=1
8.7.2. BAUD rate setting
Command format: SET●/MEDIA/UART/<P
n
>.Baudrate=0|1|2|3|4|5|6|7
Response format: pw●/MEDIA/UART/<P
n
>.Baudrate=0|1|2|3|4|5|6|7
Parameters:
.Baudrate 0 1 2 3 4 5 6 7
BAUD rate value 4800 7200 9600 14400 19200 38400 57600 115200
Example:
˃ SET /MEDIA/UART/P2.Baudrate=2
˂ pw /MEDIA/UART/P2.Baudrate=2
8.7.3. Databit setting
Command format: SET●/MEDIA/UART/<P
n
>.DataBits=8|9
Response format: pw●/MEDIA/UART/<P
n
>.DataBits=8|9
Example:
˃ SET /MEDIA/UART/P2.DataBits=8
˂ pw /MEDIA/UART/P2.DataBits=8
Page 80 / 106 LW3 programmers' reference
