Linak CB14

Page 124 of 192
CO61 - mounted on frame:
Release hook
Easy-mount bracket
3-way cable exit
Very small built-in dimension:
Height: min. 80 mm (lid can be removed)
Length: + 20 mm (locking system)
Service lid
Integrated hinge
Removable if needed
Mounting bracket (frame flat) - article No. 1015W1001:
Drawing No.: 1015W4009
Mounting bracket (frame flat) w/M4 nuts - article No. 1015W9009:
Drawing No.: 1015W4001
