Page 161 of 192
Warnings
Lithium ion batteries differ from the lead acid technology as they have a built-in deep discharge protection.
• Loss of power might happen due to the battery deep discharge protection. This will only happen in case of continuous battery use despite
warnings. In this event, there may be no warning and the application may not be able to move when expected.
• In his risk analysis, the customer must take into consideration how to ensure alternative means to make movement, e.g. quick release or
manual lowering.
• Do not open the battery housing as damaging the cell or circuitry may develop excessive heat.
• Lithium ion batteries that are defective, have been damaged or might produce excessive heat or fire are not allowed for transportation.
• The combination of CBJ1 or CBJ2 with BAJL might not be able to complete a full cycle after the audio signal of low battery warning.
• For safety reasons, please adhere to the indicated charging and operation temperature.
• In case the battery turns hot, disconnect it and evacuate the room and wait for 2 hours before taking further steps.
• The mounting instructions must be followed in order to avoid exposing batteries to water.
• Recharge batteries every 6 months at a minimum.
• Dispose of the batteries in accordance with local regulations.
DO NOT:
• Heat or burn the batteries
• Short circuit the batteries
• Expose the batteries to high impact
• Crush or puncture the batteries
• Use batteries with signs of damage or corrosion
• Charge or store the batteries near combustible material
• Expose the batteries to water or other liquids
• Overcharge or fully discharge the batteries
Compatibility:
Please be aware that BAJL Li-ion is not compatible with:
• CBJ1, CBJ2 – incl. pool lift versions
• COBO20
The control boxes CBJ1 and CBJ2 are part of the battery driven JUMBO
system. JUMBO is a modular system combining an actuator, a control box
(CBJ1, CBJ2), a battery (BAJ1) and a charger (CHJ2) in a flexible solution,
specially developed for patient lifts.
The complete system is medically approved and contains a series of
features which meet the patients need for a safe and comfortable lift, e.g.
CBJ1 and CBJ2 are equipped with a soft-start/stop function, emergency
lowering function etc.
CBJ1 and CBJ2 are available in a special edition that can be used in the
harsh conditions in the pool environment both outdoor and indoor.
Usage:
• CBJ1/CBJ2 with internal charger: Nominal current draw max. 400 mA
Power consumption (standby) max. 2.5 W
Power consumption (charging) max. 19 W
• Duty cycle: max. 10 % or 2 min. continuous use then 18 min. without use
• Ambient temperature: +5 °C to +40 °C
• Storage temperature: -10 °C to +50 °C
• Approvals: IEC60601-1, ANSI/AAMI ES60601,
CAN/CSA-22.2 No 60601-1
• For one or two actuators (lift and leg spreader actuator)
3. CBJ1/CBJ2 (MEDLINE
®
CARELINE
®
)
