22. HD80 JUMBO (MEDLINE
®
CARELINE
®
)
The HD80 JUMBO is a hand control with an optimised ergonomic design and functions
that are activated via dome buttons.
Usage:
• Usage temperature: 5º C to 40º C
• Storage temperature: -10º C to +50º C
• Compatibility: Only compatible with CBJ Care
• Relative humidity: 20% to 90% at 30º C - not condensing
• Atmospheric pressure: 700 to 1060 hPa
• Flammability rating: UL94-V2
• Approvals: IEC60601-1, ANSI/AAMI ES60601-1 and
CAN/CSA-22.2 No 60601-1
Warnings
• Do not sit or lie on the hand control. It can cause unintended movement of the application.
• Always use O-ring on connectors and cable locks.
• There is a risk that items with internal magnet for mounting instead of hook can disturb cardiac pacemaker functions, implantable cardioverters,
defibrillators or magnetic implants.
Recommendations
• Clean the hand control regularly to ensure good hygiene standards.
• When a defective HD80 is replaced, check that the new HD80 has exactly the same specification and functionality.
• Do not submerge the hand control under water.
• Unless otherwise specified or agreed by LINAK, the hand control is only intended to be used on LINAK systems.
• When changing hand controls for OpenBus™, the power must be switched off.
• It is recommended to check the hand control and cable for damage and holes made by violent handling before washing the bed or at least once a year.
• In order to maintain the flexibility of the cables, it is important that a coiled cable is placed in such a way that the cable’s own weight does not
strain the coil during the washing process.
Hand controls with magnets:
• If hand controls with magnet are hooked on a smooth surface, a movement or twisting of the cable, for instance during transport, can cause the
hand control to move and result in damage, if the cable is squeezed somewhere.
• The force of the magnet depends on the lacquering thickness, the lacquering type, stickers, steel thickness etc. The customer has the responsibility
to verify that the holding force on the application is acceptable.
• The user/operator is responsible for evaluating any potential risk caused by the use of magnets.
• It is recommended to have a parking spot for the hand control on the application where the customer ensures that the hand control does not fall off.
The HL70 is a hand control with integrated locking function, where a
selective locking of the different functions is available by use of a special
key.
The HL70 is an alternative to the HB70 combined with an attendant
Control Panel (ACM, ACL, etc.).
23. HL70 (MEDLINE
®
CARELINE
®
)
Usage:
• Exchangeable with HB70
• Compatible with many LINAK control boxes
• Approved according to: IEC60601-1:2005 3
rd
edition, ANSI / AAMI ES60601-1:2005, 3
rd
edition, and CAN / CSA-22.2 No 60601-1:2008
Recommendations
• To switch between locked and unlocked position a small knob between the two push buttons has to be turned 20° by use of a special key.
The key is for the use of the nursing staff only, there are two types, one is made of plastic the other metal.
• The key has to be ordered separately. Article no. for the plastic key is: 00914516, and the metal key number is: 00914721
• For all types:
Attention should be given to ensure that the channels shown correspond to the channels available on the chosen control box.
