Toggle function (Operation):
Press the “Toggle” button to toggle through all reference choices and make a selection to which reference you would like
to use. For example, the display may show 123 – press one more time and 234 is shown*. Since 3 is the bolded number, you
have now selected reference 3 and the up down buttons are running reference 3 up-down.
When activating the up down button it first displays the reference number shortly for ½ sec then the actual height.
Reference setup is set in the CBD4 using the configuration software.
The DPF will automatically find out how the system is configured; One, two, three or four references.
* If only two references exist 121 // 212 is shown in the display.
Important notes:
All actuator ports must be used.
If you create a 2 reference system (2 parallel + singles) and only use three ports on a 4-channel control box, the desk panel
will show “123”. You will be able to select reference three even through it is not connected.
The multi controller must not be used in combination with CBD4 software with the impulse drive feature. There is a risk that
the used software initiate impulse movement, toggle to the next reference and therefore cannot stop the movement until it is
back at the reference with impulse.
Memory positions:
1A The memory position will be for all references. When using memory one or two, reference one will first drive to its memory
position followed by reference two and so on.
Other functions common for DPF1C and DPF4T
Adjusting initial height
It may be necessary to adjust the displayed height due to different thicknesses of desktops etc. The DPF1C will as standard
either show 68 cm or 24.5 inch as the default desk height.
Procedure:
Press /\ and \/ keys at the same time and keep them pressed for 5 seconds. This allows the initial height to be adjusted. Until
the initial height can be adjusted, the display will show three minuses (---) hereafter the display will revert to showing the
height. The height can then be adjusted by either /\ or \/ until til desired height has been reached. The system will return to
normal operation (and give a short blink) after 5 seconds of inactivity on the keys.
The feature can be disabled via configuration in which case pressing the /\ and \/ keys at the same time will be considered an
illegal keypress.
Switch between cm and inch.
Switching between cm and inch can only be done via the DPF1C configurator.
Adjusting the light intensity of the LED display
Possible settings are Off, 6%, 12%, 19%, 25%, 37%, 50%, 75% and 100%.
The adjustment can only be done via the DPF1C configurator.
Adjusting the light timeout
Possible settings are 0-15 seconds and Off.
The adjustment can only be done via the DPF1C configurator.
