Lubrigun Pumps No. 82050, No. 82054, No. 83513, No. 82050-E575, Ser. J
Service Parts List Page 2 of 2
Item Description
@
Qty. Part number
50
CHECK WASHER (PA)
z 
1 11702
51 PRIMING CHECK
z 
1 11721
52 PRIMING CHECK SEAT
z 
1 11725
53 PRIMING PLUNGER
z 
1 11724
54 PRIMING TUBE 1 239719
55 MUFFLER 1 236833
56 MUFFLER COVER 1 236615
57 HEX. SOCKET SCREW 2 236869
58 PACKING CAP 1 11905
59 PLUNGER PACKING (NBR)
z
1 34110
60 PACKING WASHER 1 48237
61 PACKING NUT 1 11904
62 PACKING NUT GASKET
z
1 30003
63 TIE ROD 4 10294
64 SLIDE VALVE GASKET
z
1 38162
65 VALVE SLIDE & SEAT 1 83063
66 VALVE GUIDE PLATE 1 45605
67 BALL
z ©
2 66102
68 SPRING 2 56038
69 SPRING 4 55138
70 HEX. SOCKET SCREW 4 236870
71 HEX. SOCKET SCREW 4 236869
72 COVER 1 236286
73 TRIP SHOE
x
1 11475
74 TOGGLE PLATE
x
1 91331
75 TIE ROD NUT 4 51009
Chart: Item 35 Piston rod
35.1 used on Pump 82050 1 13020
35.2 used on Pump 82050-E575 1 13020-E575
35.3 used on Pump 82054 1 11761
35.4 used on Pump 83513 1 11799
Chart: Item 36 Pump tube
36.1 used on Pump 82050 1 61407
36.2 used on Pump 82050-E575 1 61407-E575
36.3 used on Pump 82054 1 61285
36.4 used on Pump 83513 1 61293
@ Remark:
© Indicates change
x Item recommended for service parts inventory.
z Item included in repair kit no. 83054.
 Item included in repair kit no 83001.
Note:
When ordering replacement parts, specify parts by part number and description.
Also, list part number and series letter of the Pump the parts are required for.
