Lubrigun Pumps No. 82050, No. 82054, No. 83513, No. 82050-E575, Ser. J
Service Parts List Page 1 of 2
Item Description
@
Qty. Part number
1
VALVE CAP
1 11470
2 TRIP ROD PIN
z
1 11472
3 VALVE CAP GASKET (Copper)
z ©
1 246816
4 AIR VALVE CASTING
©
1 237563
5 TRIP SLEEVE
1 11947
6 O-RING (NBR)
z
2 34368
7 AIR PISTON NUT
1 11337
8 AIR PISTON WASHER
2 48212
9 AIR PISTON PACKING (NBR)
x
1 34090
10 AIR PISTON BOLT
1 11329
11 AIR MOTOR PISTON ROD
z
1 11340
12 AIR PASSAGE TUBE
1 61502
13 AIR CYLINDER
x
1 61041
14 OUTLET BODY
1 40537
15 PUMP TUBE GASKET
z
1 31054
16 TRIP ROD
x
1 90691
17 PISTON ROD CONNECTOR
1 11349
18 CONNECTOR GASKET
z
1 31048
19 TRIP ROD COLLAR
1 11471
20 O-RING (NBR)
z
1 34158
21 VALVE COVER SCREW
4 236868
22 GASKET
z
1 33039
23 PACKING WASHER
z x
1 236616
24 TRIP ROD PACKING (NBR)
z x
1 236835
25 TRIP ROD PACKING NUT
1 245425
26 AIR CYLINDER GASKET (NBR coated fiber)
z ©
2 247611
27 GLAND PACKING NUT
1 12333
28 GLAND PACKING WASHER
1 48268
29 GLAND PACKING (NBR)
z
1 34180
30 GLAND GASKET
z
1 31050
31 GLAND PACKING SPACER
1 14940
32 O-RING (Polyurethane)
z
1 34572
33 U-CUP PACKING (Polyurethane)
z
1 38165
34 GLAND PACKING WASHER
1 48213
35 PISTON ROD
1
see chart
36 PUMP TUBE
1
see chart
37 COUPLING STUD
1 11346
38 COUPLING NUT
1 11345
39 PLUNGER ADAPTER
1 11344
40 BUSHING GASKET
2 31049
41 BUSHING EXTENSION
1 61273
42 BALL STOP
2 57027
43 BALL
z ©
2 66102
44 PLUNGER & BUSHING ASSEMBLY
1 90554
45 CHECK SEAT GASKET
z
1 31047
46 CHECK SEAT
z
1 11726
47 PLUNGER ROD
z
1 11723
48 CHECK STOP
1 11722
49 PRIMING CHECK PACKING (NBR)
z
1 35073
Continued, ref. to next page.
