Form 403760 Page Number - 11
Change Scale Factor
1. Press the
button to advance through the
Scale Factor digits.
2. Press the
button to change the selected
number.
NOTE: All digits can be scrolled between 0 and 9 except the
first. It can only be scrolled from 0 to 1 or from 1 to 0.
3. Press the button to advance to the next number in Scale Factor.
4. Repeat steps 2 and 3 for all five digits in Scale Factor.
Save Changes
To Save Changes and exit the programming mode:
1. Push and hold at the same time the and buttons.
2. The display will flash 3 times and go blank.
3. Press the
button and the display will turn back on.
Verify Changes
1. Verify Unit of Measure is correct.
2. Push and hold the Total button and Auto button together, to verify that the Scale Factor is
correct.
Changing the Scale Factor changes the accuracy of the meter, potentially causing it to overfill or under
fill. This has the potential to cause a mechanical breakdown.
Scale Factor Dis
p
la
y
Scale Factor Digits
