Form 403760 Page Number - 8
OPERATING MODE FUNCTIONS
These functions operate the same in Manual Mode and Auto Batch Mode.
Re-settable/Accumulated Totals
The meter has two flow totalizers. One is Re-settable Total. The other is Accumulated Total.
1. To see the Accumulated Total and the Re-settable Total:
• Press and hold the button to see the Accumulated Total.
• Continue holding the button.
• After three (3) seconds the display changes to the Re-settable Total.
2. Resettotal displays the total fluid dispensed since the Re-
settable Total was last set back to zero.
3. Press the button while viewing Resettotal to set it back
to zero.
4. Release the button to return to the operating display.
NOTE: The Accumulated Total cannot be reset unless the user changes from English units to metric units
or from metric to English units. (See Change Factory Settings, Change Unit of Measure).
Emergency Override
In case of an emergency or to interrupt a batch, the meter is equipped with an Emergency
Override.
1. Press the red button on the meter to activate the Emergency Override.
The override closes the valve, immediately stopping fluid flow.
2. After an Emergency Override, batching can continue by pulling up on the trigger.
Error Code
SF0 (Scale Factor 0) The Scale Factor setting for the meter is 0.000.
• You must set a non-zero value to properly measure fluid being dispensed.
• To input a valid Scale Factor for the meter follow the instructions in the “Change Factory
Settings” section of this manual.
All other Error Codes are for factory purposes only.
To clear the meter, press
.
Re-settable Total
