Circuit diagrams 7
Wiring diagram basic equipment page 4
A1 Charging circuit
A2 Combi-control
1A4 Drive control pedals
2B1 Joystick basic functions
2B2 Joystick basic functions 2
2B3 Joystick basic functions 3
2B4 Tilt angle sensor
3B1 Steering angle sensor
3B3 Accumulator pressure sensor 1
3B4 Accumulator pressure sensor 2
9B1 Current sensor
K2 Contactor coil
K3 Contactor coil
1S13 Travel direction switch
9S1 Switch power plug monitoring integrated
charger
1V2 Free-wheeling diode relay
1V3 Free-wheeling diode relay
X12 Connector plug charging / discharging
circuit, 6-pole
1X10 Connector plug 1A4, 4-pole
2X3 Connector plug 2B1, 6-pole
2X4 Connector plug 2B2, 6-pole
2X5 Connector plug 2B3, 6-pole
2X8 Connector plug 2B4, 4-pole
3X1 Connector plug 3B1, 4-pole
3X3 Connector plug 3B3, 2-pole
3X4 Connector plug 3B4, 3-pole
9X8 Connector plug 1S13, 6-pole
9X11 Connector plug 9M1, 3-pole
9X15 Connector plug transfer special equipment,
18-pole
9X16 Connector plug transfer special equipment,
12-pole
Wire colours
BK Black
BN Brown
BU Blue
GN Green
GY
Grey
OG
Orange
RE Red
VT
Purple
WH White
YE Yellow
The number before the wire colour refers to
the wire cross-section.
Wires without specification of cross-sec-
tion = 0.75 mm
2
b shown activated
3
The switch is activated when the handbrake
is not applied.
Operating Instructions – 386 807 1001 EN – 03/2006 209
