e3861359
1 Adjustin
g knob steering column
2 Steering w
heel
3 Signal but
ton horn
4 Parking br
ake
5 Key switch
6 Emergency
cut-off knob
7Operating
lever (joystick) for operating
hydrauli
cs
8 Operatin
g lever (joystick) for additional hy-
draulics
(attachments) (special equipment)
9Armrestd
river’s seat
10 Accelera
tor pedal for forwards motion
11 Stop peda
l
12 Accelera
tor pedal for reverse motion
13 Driver’s
seat with seat switch
NOTE
The switc
hes for lighting, windscreen wipers
and heati
ng (special equipment) can be found
at the top
right of the driver’s protective roof
level wit
h the indicator unit.
Operating Instructions – 386 807 1001 EN – 03/2006 19
