DOOR SCHEDULES
Select which relay channels a validation
group can access
CONCEPTS
SPECIAL INFORMATION
Program door schedules before
programming validation groups.
Door schedule 0 [DS0] always allows
access to all four door relay channels.
Up to 15 door schedules can be
programmed.
UP TO 15 DIFFERENT DOOR
SCHEDULES [DS1 - DS15] CAN BE SET
RELAY
CHANNEL "A"
RELAY
CHANNEL "B"
RELAY
CHANNEL "C"
RELAY
CHANNEL "D"
EACH DOOR SCHEDULE SETS WHICH
RELAY CHANNEL(S) THAT
THE SCHEDULE CAN ACTIVATE
DOOR SCHEDULE
A
BCD
DOOR SCHEDULE
9
