AREA 12
DOOR SCHEDULES
Area 12 is used to program which of the four relay channels
can be activated by each of the fifteen door schedules. Each
validation group can use one of the fifteen door schedules.
Each of the following activities are performed in programming
Area 12. From the main menu, use [
⇑
], [
⇓
] or enter “12” on the
keypad to scroll to “Door Schedule, Enter Program Area 12”
and press [OK]. Press [
*
] when finished to return to the main
menu.
Setting the Door Schedules
➊
Use [
⇑
] or [
⇓
] to scroll to “Which Door Sch. [1-15]”. Enter 1-15 and press
[OK].
➋
Each door schedule has selectors for relay channels A, B, C & D.
0 = NO (door schedule cannot activate relay channel)
1 = YES (door schedule can activate relay channel)
Use [
⇐
] or [
⇒
] to choose which selector to change and enter a “0” to
disable or “1” to enable the relay access for that door schedule. Press
[OK] when finished.
To set more door schedules, repeat Steps 1 & 2.
AREA 12
DOOR SCHEDULES
12.1
12.2
Which Door Sch. [1-15].
Door Schedule Number: 0
Select Valid Doors ABCD
DS[1]: 0=No, 1=Yes: 1111
50
