Table 62. Channel Assignment Data for Sense Resistor (Value = 10.0kΩ)
Configuration
Field
Description # Bits Binary Data MEMORY
ADDRESS 0x23C
MEMORY
ADDRESS 0x23D
MEMORY
ADDRESS 0x23E
MEMORY
ADDRESS 0x23F
(1) Sensor Type Sense Resistor 5 11101 1 1 1 0 1
(2) Sense
Resistor Value
10.0kΩ 27 000100111000100000000000000 0 0 0 1 0 0 1 1 1 0 0 0 1 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Table 61. Channel Assignment Data Differential Thermistor (44004/44033 2.252kΩ at 25°C Type Thermistor, Differential
Configuration with Sharing and No Rotation, R
SENSE
on CH
16
, 10µA Excitation Current)
Configuration
Field
Description # Bits Binary Data MEMORY
ADDRESS 0x24C
MEMORY
ADDRESS 0x24D
MEMORY
ADDRESS 0x24E
MEMORY
ADDRESS 0x24F
(1) Thermistor
Type
44004/44033
2.252kΩ at
25°C
5 10011 1 0 0 1 1
(2) Sense
Resistor Channel
Pointer
CH
16
5 10000 1 0 0 0 0
(3) Sensor
Configuration
Differential,
No Rotate
and Shared
3 010 0 1 0
(4) Excitation
Current
10µA
Excitation
Current
4 0101 0 1 0 1
Not Used Set These
Bits to 0
3 000 0 0 0
(5) Custom RTD
Data Pointer
Not Custom 12 000000000000 0 0 0 0 0 0 0 0 0 0 0 0
