7. MOUNT WIRELESS KEYPAD
TABLE-TOP USE
★ The wireless keypad can be used as a
portable keypad.
★ Four anti-mar pads are provided as scratch
deterrent “feet” for the keypad.
✍ NOTE: Do not use the adhesive “feet” if the
keypad is going to be wall mounted.
☞Peel off the adhesive tape backing on the
“feet” and stick them to the back of the
keypad.
WALL MOUNT USE
★ The wireless keypad can be wall mounted in
a convenient location.
☞Open the case as shown in the figure.
☞Attach the rear case to the wall using the
four screws provided.
✍ NOTE: The keypad should be mounted at
least three feet above ground level.
☞Hook the bottom edge of the keypad case
together and snap the keypad onto the rear
case.
✍ WARNING: The wireless keypad is designed
for indoor use only.
13 OF 40
USE THE FOUR SCRATCH
DETERRENT PADS PROVIDED
FOR TABLE TOP USE
FROM TOP OF CASE
TWIST SCREWDRIVER
BETWEEN CASE HALVES
UNTIL IT POPS OPEN
ATTACH REAR CASE TO WALL
WITH THE FOUR SCREWS PROVIDED
MOUNT AT A CONVENIENT
LOCATION NEAR PRIMARY
ENTRY/EXIT DOOR
FIRST, HOOK BOTTOM
EDGE TOGETHER
THEN, SNAP CASE SHUT
Defiant SSD DF-16 Owner’s Manual
Linear P/N: 208968 C
Material: 20# White Mead Bond with 60# White Coated Cover
Ink: PMS 548 (Blue/Gray)
Size: 8 1/2" x 5 1/2"
