9. PREPARING THE CONSOLE
LABELING YOUR SENSORS
★ The two sensors provided are
pre-programmed as sensors 01 and 02.
★ A label sheet with sensor location names is
provided with the Console.
☞Open one protected door/window.
☞Choose a label that describes the sensor
location, or write the location on a blank
label, and stick it in the area to the right of
the sensor light.
☞Close the protected opening that you just
labeled.
☞Repeat for each protected opening.
☞Press the [AUTO] key on the wireless keypad.
◗ The sensor 16 status light should go on for a
few seconds.
☞Stick the KEYPAD label in the spot for
sensor 16.
16 OF 40
E
M
E
R
G
E
N
C
Y
USE LABELS PROVIDED
TO IDENTIFY SENSORS
Defiant SSD DF-16 Owner’s Manual
Linear P/N: 208968 C
Material: 20# White Mead Bond with 60# White Coated Cover
Ink: PMS 548 (Blue/Gray)
Size: 8 1/2" x 5 1/2"
14
