M565Li OWNER’S/OPERATOR’S MANUAL
16. MAINTENCE
76
Handlebars Adjustment
Improper handlebars adjustment or incorrect tightening of adjuster block
bolts can cause limited steering or loosening the handlebars, resulting in
loss of control and possible serious injury or death.
Handlebars can be adjusted for your personal preference.
1.
Remove the handlebars cover.
2.
Loosen the four bolts.
3.
Adjust handlebars to the desired position.
Be sure handlebars do not hit fuel tank or
any other part of the machine when fully
turned to left or right.
4.
Torque handlebar adjuster block to 14-16 Nm.
NOTE: Tighten bolts so there is an equal gap in the front and rear of the
handlebar block. Improper gap will result in improper fit of upper pod.
Following items should be checked occasionally for tightness; or if they have
been loosened for maintenance service.
Wheel Nut Torque Specifications
Bolt Size Tightening Torque
Front （ALUMINUM WHEEL）
M12 x 1.25
95 Nm
Rear （ALUMINUM WHEEL)
M12 x 1.25
95 Nm
NOTE: All nuts that have a cotter pin installed must be serviced by an
authorized Dealer.
