Appendix D: Configuring a Gateway-to-Gateway IPSec Tunnel
Overview
Appendix D: Configuring a Gateway-to-Gateway IPSec Tunnel
Overview
This appendix explains how to configure an IPSec VPN tunnel between two VPN Routers by example. Two PCs are
used to test the liveliness of the tunnel.
Before You Begin
The following is a list of equipment you need:
• Two Windows desktop PCs (each PC will be connected to a VPN Router)
• Two VPN Routers that are both connected to the Internet
Configuring the VPN Settings for the VPN Routers
Configuring VPN Router 1
Follow these instructions for the first VPN Router, designated VPN Router 1. The other VPN Router is designated
VPN Router 2.
NOTE: Each computer must have a network
adapter installed.
Figure D-1: Diagram of All VPN Tunnels
PC 1 PC 2VPN Router 1 VPN Router 2
