15
Chapter 6: Setting Up and Configuring the Router
How to Access the Web-based Utility
4-Port Gigabit Security Router with VPN
• Report. Provides report of network traffic and malicious attacks.
• Information. Provides the Protection Scope of the router.
L2 Switch
• VLAN. Virtual Local Area Network (VLAN) categorization is done from this screen.
• RADIUS. Used for configuration of Remote Authorization Dial-In User Service (RADIUS) settings.
• Port Setting. Allows configuration of port speeds and duplex.
• Statistics. Displays transmit and receive statistics.
• Cable Diagnostics. Used for testing cabling connected to the LAN ports.
Status
• Gateway. This screen provides status information about the Router.
• Local Network. This provides status information about the local network.
• VPN Clients. This screen provides status information about the Router’s VPN clients.
How to Access the Web-based Utility
The router is configured using the built-in Web-based utility. To access the Web-based Utility of the Router:
• Launch Internet Explorer or Netscape Navigator, and enter the Router’s default IP address, 192.168.1.1, in
the Address field. Press the Enter key.
• A screen will appear asking you for your User name and Password. Enter admin in the User Name field, and
enter your password (default password is admin) in the Password field. Then click the OK button.
Figure 6-1: Router’s IP Address
Figure 6-2: Password
