31
Chapter 6: Using the Web-based Utility
The Voice Tab
IP Telephony System
The Voice Tab
The Voice - Info Screen
This screen shows voice-related settings for the System.
Product Information
Product Name. Shown here is the model number of the System.
Serial Number. Shown here is the serial number of the System.
Software Version. Shown here is the version number of the System software.
Hardware Version. Shown here is the version number of the System hardware.
MAC Address. Shown here is the MAC address of the System.
Client Certificate. Shown here is the status of the client certificate, which indicates that the System has been
authorized by your ITSP.
Licenses. This indicates how many additional licenses you have acquired for the System.
System Status
Current Time. Displayed here is the current date and time of the System.
Elapsed Time. Displayed here is the amount of time elapsed since the last reboot of the System.
FXS 1/2 Status
The FXS 1 and FXS 2 ports are the Phone ports of the System. (You can connect analog phones or fax machines to
both ports.) They have the same status information available.
Hook State. Displayed here is the status of the phone’s readiness. On indicates that the phone is ready for use,
while Off indicates that the phone is in use.
Message Waiting. This indicates whether you have new voicemail waiting.
Call Back Active. This indicates whether a call back request is in progress.
Last Called Number. Displayed here is the last number called.
Figure 6-8: Voice - Info Screen - Product Information
Figure 6-9: Voice - Info Screen - System Status
