Rev: 11.19.20 Page 2 CCD-0002764
TABLE OF CONTENTS
Introduction 2
Safety 3
Important Safety Information 3
Resources Required 4
Installation 4
Drive Shaft and Motor Installation 4
Belt and Stabilizer Guide Track Brackets 10
Belt Mounting Brackets 12
Stabilizer Channel Guides 15
Key Switch 16
Wiring Harness Connections 17
Wiring Diagram 18
Setting the ACS Stop Procedure 19
Flex Track For Wires 20
Safety Belt Harness 21
Operation 22
Prior to Operating the Bed Lift System 22
Lowering the Bed Lift 22
Raising the Bed Lift 22
Manual Override 23
Maintenance 23
Introduction
The Bed Lift distributed by Lippert Components, utilizes a unique nylon strap-based system, adaptable to
a broad range of RV and heavy truck applications including cabs, living rooms, slide-out rooms and master
bedrooms. The straps retract into the bed base, concealing the lifting system in the retracted position,
permitting OEMs more floor plan design freedom. The nearly silent Bed Lift system is operated by a single
motor that controls four support mounts to raise and lower the bed at 58.4 mm (2.3 in) per second. The
363 kg (800 lbs) capacity system can be customized in both size and configuration to maximize space in
any motorhome, towable RV or truck cab floor plan design. The system can even “bend” to conform to wall
curvatures found in some motorhome cabs.
For information on the assembly or individual components of this product, please visit:
https://support.lci1.com/beds.
NOTE: Images used in this document are for reference only when assembling, installing and/or operating
this product. Actual appearance of provided and/or purchased parts and assemblies may differ.
Additional information about this product can be obtained from lci1.com/support or by using the myLCI
app. Replacement kits can be ordered from https://store.lci1.com/ or by using the myLCI app.
The myLCI app is available for free on iTunes® for iPhone® and iPad® and also on Google Play™ for Android™
users.
iTunes®, iPhone®, and iPad® are registered trademarks of Apple Inc.
Google Play™ and Android™ are trademarks of Google Inc.
