Rev: 08.30.22 Page 45 CCD-0006500
What Is Happening? Why? What Should Be Done?
Swivel barrel not
secured.
Debris lodged inside
the locking plate.
Remove debris from locking plate.
Damaged or worn slide
button spring.
Replace hinge assembly.
Swivel barrel won’t
release from locking
plate.
Debris lodged inside
the locking plate.
Remove debris from locking plate.
Damaged or worn slide
button spring.
Replace hinge assembly.
Front support arm does
not staysecured.
Damaged or worn EZ
Clip.
Replace EZ Clip.
Front support arm does
not reach the hinge
assembly.
Bimini top not fully
open.
Fully open the power bimini top until the
auto-reset breaker trips.
H-bracket and/or hinge
assembly not properly
installed.
Contact Lippert Customer Care Center.
