TP0003B
BM BULKMETER
Chap 7
Page 13
SPARE PARTS
Fig/
Item No.
Part No. Description Qty
7-2
1 NOT SPARED CALIBRA TING MECHANISM BASE SUB ASSEMBLY REF
2 ZASZ0029-2 DOWEL PIN, 1/4” X 1 1/2” 2
3 ZS3226E0832A BOLT, HEX HD, 1/4” UNF X 2” 4
3A ZW8207G08A WASHER 1/4” SINGLE COIL 4
4 SEE TABLE 10 ROTOR GEAR 1
5 ZT8001E0308A TENSION PIN 3/32” X 1/2” 1
6 + SEE TABLE 10 DRIVING GEAR SUB ASSEMBLY comprising: 1
7 . DRIVING SPINDLE REF
8 . DRIVING GEAR REF
9 . INTERMEDIATE GEAR REF
10 . TENSION PIN (2) REF
11 BMRZ36 SPINDLE SEAL 1
12 NOT SPARED CALIBRATING GEAR BRACKET SUB ASSEMBLY REF
13 ZS3225M05016A SCREW M5 X 16mm SKT.HD. 5
14 ZW2201M05A WASHER M5 PLAIN 8
15 ZASZ0104-5 DOWEL PIN, 3/16” X 1/2”, SILV STL 2
16 BMMS66 SUN GEAR SUB ASSEMBLY comprising: 1
17 . SUN GEAR, 12T REF
18 . WORM GEAR, 28T REF
19 . TENSION PIN, 3/32” X 7/16”, SP STL REF
20 BMMS4021 PLANET WHEEL CARRIER SUB ASSEMBLY comprising: 1
. CARRIER, PLANET WHEEL REF
. GEAR, 34T REF
.PIN REF
. TENSION PIN, 1/16” X 5/16”, SP STL REF
21 BMCZ10340 PLANET GEAR 1
22 BMCZ10339 BALANCE WEIGHT 1
23 SEE TABLE 11 SPIRAL GEAR SUB-ASSEMBLY 1
24 BMSZ53 SPIRAL GEAR STUD 1
25 BMSZ54 COLLAR 1
26 ZT8001E0308A TENSION PIN 3/32” X 1/2” 1
27 ZN2201B08A NUT 1/4” BSF 1
28 ZW8207G08A WASHER 1/4” SINGLE COIL 1
29 ZAMZ0077-2 BALL BEARING/THRUST WASHERS 1
30
BMSZ90 FRICTION DISC SPRING 1
* = SUGGESTED SPARE PART + = NOT ILLUSTRATED
