TP0003B
BM BULKMETER
Chap 7
Page 15
SPARE PARTS
Fig/
Item No.
Part No. Description Qty
7-2
31 + BMMS17228 DISC GEAR SUB ASSEMBLY comprising: 1
32 BMSZ70 . SPINDLE, FRICTION DISC 1
33 BMSZ73 . DISC, FRICTION DRIVE 1
34 BMMZ17248 . SHELL/DISC GEARS ASSEMBLY 1
35 ZS2203A0504A . SCREW, 5BA X 1/4”, CH.HD. 2
36 + BMMS77 CALIBRATOR WORM SHAFT SUB ASSEMBLY comprising: 1
37 . CALIBRATOR, WORM SHAFT 1
38 . FRICTION ROLLER 1
39 . SKT GRUB SCREW, CUP POINT, HTS, M5 X 6MM 1
40 BMMS80 CALIBRATING SCREW SUB ASSEMBLY 1
41 BMCZ78 NUT, SPECIAL 1
42 ZS2203A0210A SCREW CH.HD. 2BA X 5/8” 1
43 SEE TABLE 12 INTERMEDIATE SHAFT SUB ASSEMBLY (WITH CLUTCH)
incorporating ITEMS 44 TO 49
1
43A SEE TABLE 12 INTERMEDIATE SHAFT SUB ASSEMBLY (WITHOUT
CLUTCH) incorporating ITEMS 44A, 45, 46 AND 47A
1
47 SEE TABLE 13 DRIVE GEAR 1
48 ZASZ0035-17 SHIM WASHER 1
49 ZASZ0058-4 CIRCLIP 1
50 BMAS33225
BMAS33225M
CALIBRATING MECHANISM COVER,
NO RATE OF FLOW
CALIBRATING MECHANISM COVER,
FOR RATE OF FLOW
1
51 BMSZ32988 FLAT PLATE 1
52 BMDZ109 GASKET 1
53 ZMSZ0111-16 SEALING SCREW M5 X 16mm 2
* 54 BMDZ33226 GASKET, CALIBRATING MECHANISM COVER 1
55 BMSZ2362 SCREW SPECIAL SEALING 2
56 ZS3228E0812A SCREW 1/4” UNF x 3/4” 2
57 ZW8205G08A WASHER 1/4” EXT. SHAKEPROOF 4
58 INFORMATION ONLY REGISTER -
59
SEE TABLE 14 REGISTER DRIVING GEAR -
* = SUGGESTED SPARE PART + = NOT ILLUSTRATED
