TP0003B
BM BULKMETER
Chap 8
Page 5
RATE OF FLOW INDICATOR
Fig/
Item No.
Part No. Description (Qty)
8.1--
1 BMMZ33284 RATE OF FLOW INDICATOR AND COVER
ASSEMBLY
1
2 ZS3225M04016A CLAMPING SCREW 1
3 BMAZ33220 GEAR BRACKET 1
4 BMSZ33222 STUD 1(LH) 2(RH)
5 SEE TABLE 1 DRIVING PINION 1
6 ZT8001E0207A TENSION PIN 1/16 IN DIA. 1
7 SEE TABLE 1 COMPOUND GEAR 1
8 ZASZ0058-3 CIRCLIP TYPE 1500-147E 1(LH) 2(RH)
9 ZACZ0003-75 IDLER GEAR 0(LH) 1(RH)
10 ZW2203A02A WASHER 2BA 1(LH) 2(RH)
11
ZN2201E06A NUT 10-32 UNF 1(LH) 2(RH)
* = SUGGESTED SPARE PART
TABLE 1
FIG 8.1 - RATE OF FLOW INDICATOR AND COVER ASSEMBLY (Including all items shown in Fig 8.1)
METER TYPE
GALLONS US GALLONS LITRES / DECALITRES
LH SINGLE BMMS33227-GSL BMMS33227-USL BMMS33227-GSL
DOUBLE BMMS33227-GDL BMMS33227-UDL BMMS33227-DDL
TRIPLE BMMS33227-GTL BMMS33227-UTL BMMS33227-DTL
RH SINGLE BMMS33227-GSR BMMS33227-USR BMMS33227-GSR
DOUBLE BMMS33227-GDR BMMS33227-UDR BMMS33227-DDR
TRIPLE BMMS33227-GTR BMMS33227-UTR BMMS33227-DTR
