TP0003B
Appendix to Chap 8
Page 2
Fig/
Item No.
Part No. Description (Qty)
8A.1-
1
BMAZ33220 GEAR BRACKET 1
2 BMDZ5178 GASKET 1
3 ZS2203M03035A SCREW 3
4 ZW8206M03A WASHER 3
5 ZS3225M04016A CLAMPING SCREW 1
6 ZT8001E0207A TENSION PIN 1/16 IN DIA. 1
7SEETABLE1 INDICATOR 1
8 BMSZ33222 STUD 2
9 ZASZ0058-3 CIRCLIP TYPE 1500 -147E 2
10 ZW2203A02A WASHER 2BA 2
11 ZN2201E06A NUT 10-32 UNF 2
12
BMMS33253 GLASS (REP AIR KIT) 1
TABLE 1
FIG 8A.1, RATE OF FLOW INDICATOR RETROFIT TO MK2A CALMECHS.
METER TYPE
GALLONS / LTRS US GALLONS
SINGLE BMMS33261--GS BMMS33261--US
DOUBLE BMMS33261--GD BMMS33261--UD
TRIPLE BMMS33261--GT BMMS33261--UT
FIG 8A.1 -- ITEM 7 -- INDICATOR
METER TYPE
LITRES/GALLONS US GALLONS
SINGLE BMMZ33285--GS BMMZ33285--US
DOUBLE BMMZ33285--GD BMMZ33285--UD
TRIPLE BMMZ33285--GT BMMZ33285--UT
