Liquid Controls M Series Installation Manual

BILL OF MATERIALS BILL OF MATERIALS
Meter components may appear
different between models.
Meter components may appear
different between models.
M60, M80 Meter cover M60, M80 Meter eleMent
Numbers shown are item numbers, not part numbers. Refer to the Bill of Materials M610 supplied in
the red Owner’s Information Packet to locate the part number associated with these item number.
Item Numbers and Part Numbers
Numbers shown are item numbers, not part numbers. Refer to the Bill of Materials M610 supplied in
the red Owner’s Information Packet to locate the part number associated with these item number.
Item Numbers and Part Numbers
27
26

Liquid Controls M Series Specifications

General

Temperature Range	-40°F to +160°F (-40°C to +71°C) standard, extended ranges available
Materials	stainless steel
Type	Positive displacement flow meter
Fluid Compatibility	fuels, oils, and chemicals
Sizes	6"
Output Options	Pulse
