LiteOn EVO600043S1D5E20F User Manual

185
Register No.
Definitions
Bit 14
Multi-Function Terminal 7 (1: ON)
Bit 15
Multi-Function Terminal 8 (1: ON)
2402H
Frequency Command (0.01Hz Units)
 Monitor Data (Read Only)
Register No.
Definitions
2420H
Retain
2421H
Opeartion Status
Bit 0
1: During Run
Bit 1
1: During reverese
Bit 2
1: During Zero speed
Bit 3
1: During fault
Bit 4
1: During alarm detecton
Bit 5
1: During speed agree
Bit 6
1: During ready
Bit 7
1: Frequency command provided from
communication
Bit 8
1: Run command provided from Remote
communication
Bit 9
Retain
Bit 11 to 15
Retain
2422H
Frequency command (0.01Hz
units)
2423H
Output frequency (0.01Hz units)
2424H
Output current (0.1A units)
2425H
Output voltage (0.1V units)
2426H
DC voltage (0.1V units)
2427H
Alarm description
2428H
Fault description
2429H
Multi-Function Inputs and Outputs Status
Bit 0
1: Multi-Function Terminal 1 ON
Bit 1
1: Multi-Function Terminal 2 ON
Bit 2
1: Multi-Function Terminal 3 ON
Bit 3
1: Multi-Function Terminal 4 ON
Bit 4
1: Multi-Function Terminal 5 ON
Bit 5
1: Multi-Function Terminal 6 ON
