LiteOn EVO600043S1D5E20F User Manual

186
Bit 8 to 10
Retain
Bit 12
1: Relay 1 ON
Bit 14
Retain
Bit 15
Retain
242AH
AI1 input (0 equals 0V or 0mA, 1000 equals 10V or 20mA)
242BH
communication
242CH
Retain
242DH
AO1 input (0 equals 0V, 1000 equals 10V)
242EH
communication
 Alarm Data (2427H)
No.
Contents
No.
Contents
No.
Contents
0
No alarm
13
Retain
26
Ut1 (Undertorque
Detection 1)
1
EF0 (Communication
Fault)
14
Retain
27
Retain
2
EF1 (External Fault 1)
15
Retain
28
Retain
3
EF2 (External Fault 2)
16
Retain
29
Retain
4
EF3 (External Fault 3)
17
Retain
30
Retain
5
EF4 (External Fault 4)
18
FbH (PID Feedback High)
31
BB(Baseblock)
6
EF5 (External Fault 5)
19
FbL (PID Feedback Low)
32
OH2 (Heatsink Overheat
warning)
7
EF6 (External Fault 6)
20
OH (Heatsink Overheat)
33
HCA(Current Alarm)
8
Retain
21
Retain
34
DNE (Drive Disable)
9
Retain
22
ot1 (Overtorque Detection
1)
35
Retain
10
Retain
23
Retain
36
CE (Modbus
Communication Error)
11
Retain
24
Ov (Overvoltage)
37
Retain
12
Retain
25
Uv(Undervoltage)
38
Retain
