Table 6.20 Multi-Function Output Terminal Settings
Setting
Function
Setting
Function
0
During Run
29
Retain
1
Zero Speed Holding
30
Retain
2
Frequency (Speed) Agree
31
Retain
3
User-Defined Frequency (Speed ) Agree
32
Retain
4
Drive Ready
33
Retain
5
Uv (Undervoltage) Detection
34
Retain
6
During Baseblock
35
During Frequency Output
7
Retain
36
Drive Enabled
8
Frequency Command Source
37
Retain
9
Frequency Command Loss
38
Local/Remote Mode
10
Run Command Source
39
During Speed Search
11
Fault
40
PID Feedback Low
12
Communication Mode
41
PID Feedback High
13
Alarm
42
Retain
14
Fault Restart
43
Retain
15
Retain
44
During Fast Stop
16
Frequency (FOUT) Detection 1
45
Retain
17
Frequency (FOUT) Detection 2
46
Retain
18
Overvoltage/Undervoltage Detection 1
47
Retain
19
Retain
48
Retain
20
Retain
49
Retain
21
Retain
100~149
0~49 Inverse Output
22
During Reverse
23
Retain
24
During Regeneration
25
Restart Enabled
26
Motor Overload Pre-Alarm (oL1)
(Including oH3)
27
Drive Overheat Pre-Alarm (oH)
28
Retain
0 : During Run
When the drive is outputting voltage, the output terminal closes.
Terminal
Description
Open
The drive is stopped.
