E4 Multi-Function Analog Output
These parameters assign functions to terminal FM and AM to monitor the status of the drive.
 E4-01 Terminal FM Monitor Selection
Selects the monitor for terminal FM and AM.
No.
Name
Setting Range
Default
E4-01
Terminal FM Monitor Selection
0 to 11
1
Setting
Function
0
Frequency Command
1
Output Frequency
2
Output Current
3
Motor Speed
4
Output Voltage
5
DC Voltage
6
Output Power
7
Retain
8
AI1 Input
9
Retain
10
Soft Starter Output Frequency
11
Retain
 E4- 02/ E4- 03 Terminal FM Monitor Gain / Voltage Bias
E4-02 Sets the gain for terminal FM as a percentage.
E4-03 Sets the voltage bias for terminal FM as a percentage.
10 V equals 100% when setting E4-02, E4-03.
Figure 6.69 illustrates the gain and bias operation.
No.
Name
Setting Range
Default
E4-02
Terminal FM Monitor Gain
-999 to 999.9%
100.0%
E4-03
Terminal FM Voltage Bias
-999 to 999.9%
0.0%
