High Detection.

 b5- 11 PID Feedback Low /High Detection Selection

Sets the feedback low /high detection and the operation when it is detected.

No.

Name

Setting Range

Default

b5-11

PID Feedback Low /High Detection Selection

0 to 5

0 : Multi-Function Output Only

A multi-function output set for E2-□□= 40 (PID feedback low) will be triggered if the PID

feedback value is lower than the detection level set to b5-12 for longer than the detection time

set to b5-13

A multi-function output set for E2-□□= 41 (PID feedback high) will be triggered if the PID

feedback value is higher than the detection level set to b5-22 for longer than the detection

time set to b5-23

No alarm or fault will be triggered. The drive will continue operation. The output resets when

the PID feedback value returns to the normal range.

1 : Feedback Low /High Alarm

A FbL (PID feedback low) alarm and a multi-function output set for E2-□□= 40 (PID feedback

low) will be triggered if the PID feedback value is lower than the detection level set to b5-12

for longer than the detection time set to b5-13, the keypad

A FbH (PID feedback high) alarm and a multi-function output set for E2-□□= 41 (PID feedback

high) will be triggered if the PID feedback value is higher than the detection level set to b5-22

for longer than the detection time set to b5-23

A multi-function output set for E2-□□=13 (alarm) will be triggered in either event. The drive

will continue operation. The alarm resets when the PID feedback value returns to the normal

range.

2 : Feedback Low /High Fault

A FbL (PID feedback low) fault will be triggered if the PID feedback value is lower than the

detection level set to b5-12 for longer than the detection time set to b5-13, the keypad

A FbH (PID feedback high) fault will be triggered if the PID feedback value is higher than the

detection level set to b5-22 for longer than the detection time set to b5-23

A multi-function output set for E2-□□=11 ( fault) will be triggered in either event to cause the

drive to stop the motor.

3 : Multi-Function Output only, even if PID is Disabled

Same as b5-11= 0.
