LiteOn EVO600043S2D2E20F - Page 90

90
A
60 Hz, mid starting torque
· Large starting torque is required such as
elevators.
· AC reactor is installed on the drive output
side
B
60 Hz, high starting torque
C
90 Hz (with 60 Hz base)
Fixed Output
Constant output voltage when running at
60 Hz and above.
D
120 Hz (with 60 Hz base)
E
180 Hz (with 60 Hz base)
The characteristics of the V/F patterns are illustrated in the following table. The table shows the
V/F patterns for 200V. The voltage will be doubled for 400V.
Table 6.14 Constant Torque Characteristics (Setting 0 to 3)
Setting = 0
50 Hz
Setting =1
60 Hz
Setting =2
60 Hz
Setting =3
72 Hz
V
0 1.3 2.5 50
7
14
230
Hz
0 1.5 3 60
7
14
230
V
Hz
0 1.3 2.5 60
7
14
230
50
V
Hz
0 1.5 3 60
7
14
230
72
V
Hz
Table 6.15 Derated Torque Characteristics (Setting 4 to 7)
Setting =4
50 Hz
Setting =5
50 Hz
Setting =6
60 Hz
Setting =7
60 Hz
0 1.3 25 50
8
35
230
Hz
V
0 1.3 25 50
9
50
230
Hz
V
0 1.3 30 60
8
35
230
Hz
V
0 1.5 30 60
9
50
230
Hz
V
Table 6.16 High Starting Torque Characteristics (Setting 8 to B)
Setting =8
50 Hz
Setting =9
50 Hz
Setting =A
60 Hz
Setting =B
60 Hz
