Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 276
Measurement Panel
Measurements, Features, and Settings
Measurement Illustration
Major
Determines the major axis length of an ellipse fitted to the
part's area in the XY plane.
Minor
Determines the minor axis length of an ellipse fitted to the
part's area in the XY plane.
Ratio
Determines the minor/major axis ratio of an ellipse fitted to
the part's area in the XY plane.
Measurements
