Gocator Line Profile Sensors: User Manual
Gocator Device Files • 431
Tool
A Tool element of type FeatureDimension defines settings for a feature dimension tool and one or more
of its measurements.
Element Type Description
@type String Type name of the tool.
@version String Version string for custom tool.
Name String Tool name.
Source 32s Surface source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Y String (CSV) The Y measurements (IDs) used for anchoring.
Anchor\Y.options String (CSV) The Y measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
Parameters\RefPoint
GdkParamGeometricFeature
Reference point feature.
Parameters\Feature GdkParamGeometricFeature Reference feature.
Measurements\Measurement
@type=Width
Dimension Measurement
Width measurement.
Measurements\Measurement
@type=Length
Dimension Measurement Length measurement.
Measurements\Measurement
@type=Height
Dimension Measurement Width measurement.
Measurements\Measurement
@type=Distance
Dimension Measurement Distance measurement.
Measurements\Measurement
@type=PlaneDistance
Dimension Measurement Plane distance measurement.
Tool Child Elements
@id 32s
Measurement ID. Optional (measurement disabled if not
set).
@type String Type name of measurement.
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
Dimension Measurement Child Elements
