Gocator Line Profile Sensors: User Manual
Gocator Web Interface • 188
Point Type Examples
Left Corner
Finds the left-most corner in the region of interest, where corner
is defined as a change in profile shape.
Right Corner
Finds the right-most corner in the region of interest, where
corner is defined as a change in profile shape.
Rising Edge
Finds a rising edge in the region of interest (moving from left to
right).
Falling Edge
Finds a falling edge in the region of interest (moving from left to
right).
Any Edge
Finds a rising or falling edge in the region of interest.
Median
Determines the median location of points in the region of
interest.
Fit Lines
Some measurements involve estimating lines in order to measure angles or intersection points. A fit line
can be calculated using data from either one or two fit areas.
