Gocator Line Profile Sensors: User Manual
Gocator Device Files • 439
Element Type Description
Event 32s
Triggering event:
0 – None (disabled)
1 – Measurements
2 – Software
ScheduleEnabled Bool Enables scheduling.
CurrentMin 64f Minimum current (mA).
CurrentMin.min 64f Minimum value of minimum current (mA).
CurrentMin.max 64f Maximum value of minimum current (mA).
CurrentMax 64f Maximum current (mA).
CurrentMax.min 64f Minimum value of maximum current (mA).
CurrentMax.max 64f Maximum value of maximum current (mA).
CurrentInvalidEnabled Bool Enables special current value for invalid measurement value.
CurrentInvalid 64f Current value for invalid measurement value (mA).
CurrentInvalid.min 64f Minimum value for invalid current (mA).
CurrentInvalid.max 64f Maximum value for invalid current (mA).
DataScaleMax 64f Measurement value corresponding to maximum current.
DataScaleMin 64f Measurement value corresponding to minimum current.
Delay 64f Output delay (µs or mm, depending on delay domain defined below).
DelayDomain 32s
Output delay domain:
0 – Time (µs)
1 – Encoder (mm)
Measurement 32u Selected measurement source.
Measurement.options 32u (CSV) List of available measurement sources.
Analog Child Elements
The delay specifies the time or position at which the analog output activates. Upon activation, there
is an additional delay before the analog output settles at the correct value.
Serial
The Serial element defines settings for Serial output.
Element Type Description
Protocol 32s
Serial protocol:
0 – ASCII
1 – Selcom
Protocol.options 32s (CSV) List of available protocols.
Selcom Section
See Selcom on the next page.
Ascii Section
See Ascii on the next page.
Serial Child Elements
