Gocator Line Profile Sensors: User Manual
Gocator Device Files • 433
Element Type Description
Measurements\Measurement
@type=Z
Intersect Measurement Z measurement.
Measurements\Measurement
@type=Angle
Intersect Measurement Angle measurement.
Features\IntersectPoint
GDKFeature
Intersect point feature.
@id 32s
Measurement ID. Optional (measurement disabled if not
set).
@type String Type name of measurement.
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Parameters\AngleRange GdkParamInt
Angle range option choice. Is one of:
0 – -180 To 180
1 – 0 To 360
Intersect Measurement Child Elements
Custom
A Custom element defines settings for a user-created GDK-based tool and one or more of its
measurements.
Element Type Description
@type String Type name of the tool.
Custom Child Elements
