Gocator Line Profile Sensors: User Manual
Gocator Device Files • 397
Element Type Description
Line
ProfileLine
Definition of line.
Measurements\X Intersect tool
measurement
X measurement.
Measurements\Z Intersect tool
measurement
Z measurement.
Measurements\Angle Intersect tool
measurement
Angle measurement.
Features\IntersectPoint
GeometricFeature
IntersectPoint PointFeature.
Features\Line GeometricFeature Line LineFeature.
Features\BaseLine GeometricFeature BaseLine LineFeature.
Element Type Description
@id 32s Measurement ID. Optional (measurement disabled if not
set).
Name String Measurement name.
Enabled Boolean
Measurement enable state:
0 – Disable
1 – Enable
HoldEnabled Boolean
Output hold enable state:
0 – Disable
1 – Enable
SmoothingEnabled Boolean
Smoothing enable state:
0 – Disable
1 – Enable
PreserveInvalidsEnabled Boolean Preserve invalid measurements enable state
0 – Disable
1 – Enable
SmoothingWindow 32u Smoothing window.
Scale 64f Output scaling factor.
Offset 64f Output offset factor.
DecisionMin 64f Minimum decision threshold.
DecisionMax 64f Maximum decision threshold.
Absolute
(Angle measurement only)
Boolean
Setting for selecting the angle range:
0 – A range of -90 to 90 degrees is used.
1 – A range of 0 to 180 degrees is used.
Intersect Tool Measurement
ProfileLine
A ProfileLine element defines settings for a profile line tool and one or more of its measurements.
