Gocator Line Profile Sensors: User Manual
Gocator Device Files • 398
Element Type Description
Name String Tool name.
Features
Collection Collection of geometric feature outputs available in the tool.
See ProfileLine on the previous page.
Source 32s Profile source.
Anchor\X String (CSV) The X measurements (IDs) used for anchoring.
Anchor\X.options String (CSV) The X measurements (IDs) available for anchoring.
Anchor\Z String (CSV) The Z measurements (IDs) used for anchoring.
Anchor\Z.options String (CSV) The Z measurements (IDs) available for anchoring.
StreamOptions Collection
A collection of StreamOptions on page 382 elements.
Stream\Step
32s The stream source step. Possible values are:
1 – Video
2 – Range
3 – Surface
4 – Section
Stream\Id 32u The stream source ID.
RegionEnabled Bool Whether or not to use the region. If the region is disabled,
all available data is used.
Region
ProfileRegion2d
Measurement region.
FittingRegions
ProfileLine
ProfileLine describing up to 2 regions to fit to.
FittingRegionsEnabled Bool Whether the fitting regions are enabled.
Measurements\StdDev Line tool
measurement
StdDev measurement.
Measurements\MaxError Line tool
measurement
MaxError measurement.
Measurements\MinError Line tool
measurement
MinError measurement.
Measurements\Percentile Line tool
measurement
Percentile measurement.
Measurements\Offset Line tool
measurement
Offset measurement.
Measurements\Angle Line tool
measurement
Angle measurement.
Measurements\MinErrorX Line tool
measurement
Minimum Error in Z measurement.
Measurements\MinErrorZ Line tool
measurement
Minimum Error in Z measurement.
Measurements\MaxErrorX Line tool
measurement
Maximum Error in X measurement.
ProfileLine Child Elements
