Gocator Line Profile Sensors: User Manual
Protocols • 485
Field Type Offset Description
length 32u 0 Reply size including this field, in bytes.
id 16u 4 Reply identifier (0x4508).
status 32s 6
Reply status. For a list of status codes, see Commands on page
446.
progressTotal 32u 10 Progress indicating completion (100%).
progress 32u 14 Current progress.
Initial Reply
Field Type Offset Description
length 32u 0 Reply size including this field, in bytes.
id 16u 4 Reply identifier (0x5000).
status 32s 6
Reply status. For a list of status codes, see Commands on page
446.
progressTotal 32u 10 Progress indicating completion (100%).
progress 32u 14 Current progress.
size 32u 18 Size of the chunk in byes.
data[size] byte 22 Chunk data.
Continue Reply
Get Runtime Variable Count
The Get Runtime Variable Count command gets the number of runtime variables that can be accessed.
Field Type Offset Description
length 32u 0 Command size including this field, in bytes.
id 16u 4 Command identifier (0x4537).
Command
Field Type Offset Description
length 32u 0 Reply size including this field, in bytes.
id 16u 4 Reply identifier (0x4537).
status 32s 6 Reply status.
valueLength 32u 10 The count of runtime variables.
Reply
Set Runtime Variables
The Set Runtime Variablescommand sets the runtime variables at the given index for the given length.
Field Type Offset Description
length 32u 0 Command size including this field, in bytes.
Command
