Tangential Rolling System T18F - T27F
18
www.lmt-fette.com
The setting gauge is marked with the thread size (e. g. M16x1.5), the code number
(e. g. T27-35-4) and the 7-digit ID number of the gauge (e. g.1548947) and also the
setting dimensions F and A
v
.
For each thread size a roll set and a setting gauge are required. The first two number
groups of the code numbers of the thread roll and the setting gauge must match.
NOTICE
It is a prerequisite that the rolling head size (e. g. T27) and the consecutive
number (e. g. 35) of the setting gauge and the thread rolls must be identical
in the code number for the gauge to be suitable for the thread rolls.
