Operating Manual
Tangential Rolling System T18F - T27F
44
10 Cleaning, maintenance and servicing
10.1 Changing the thread rolls
Check the rolled profile exactly after changing the rolls. If in particular the workpiece
major diameter is not correct, compensate for this by adjusting the head setting, see
Chapter 8.
ATTENTION
It is only permitted to use thread rolls with the same roll set number
Make sure to apply a coat of molybdenum sulfide
(e. g. Molykote) to the roll hole and axes (3).
Retighten the cap screw (25) after approx. 100 rolling operations!
10.2 Maintenance intervals
The required maintenance intervals must be observed to ensure the proper function of
the rolling head. The cleaning and maintenance intervals will need to be shortened if
the rolling system is used under difficult conditions.
Interval Person responsible Task
Weekly
(recommended
daily)
Machine operator Remove the rolling head from the rolling head
holder. Ensure the rolling head and holder are
free of chips, clean if necessary. Insert the rolling
head back into the holder.
Check the axial clearance of the rolling head and
adjust if necessary (see Chapter 5.1.3)
Weekly To be performed
by fitter or foreman
only
Loosen the cap screw (ET-25) and pull out the
axis (ET-3); hold the thread roll (ET-18) with your
hand to prevent it from falling out and take it out
of the rolling head. Clean the thread roll, axis,
washer and bushing to remove any dirt and chips
and apply a light coat of molybdenum sulfide
(e. g. Molykote). Reinsert the roll
(see also Chapter 5.1.2)
Weekly To be performed
by fitter or foreman
only
Check the washer (ET-15) for even wear. Replace
both washers when:
■ the thickness of both washers differs by
> 0.05 mm l 0.02 inch from each other
■ for T18 the thickness of a washer is less than
0.45 mm l 0.018 inch
■ for T27 the thickness of a washer is less than
0.6 mm l 0.024 inch
