Operating Manual
Tangential Rolling System T18F - T27F
45
Interval Person responsible Task
Weekly To be performed
by fitter or foreman
only
Lubricate the synchronous gear with some gear
grease over the lubricating nipples (ET-21).
Alternatively, remove the lubricating nipples and
connect the rolling head directly to the central
lubrication system of machine tool (provided this
is free of contamination).
Every three
months/after a
long period of
non-use
To be performed
by fitter or foreman
only
Disassemble the complete tool and remove any
contamination or chips. Lubricate all parts during
reassembly according to guidelines.
Every three
months/after a
long period of
non-use
To be performed
by fitter or foreman
only
Visually inspect all parts for run-in marks,
especially:
■ Axis (ET-3) in the region of the carbide
bushings
■ Gears in the region of the tooth flanks
■ Pinion (ET-8) in the region of the driving cams
■ Hinge upper and lower part in the region of the
washer (ET-15)
If there is substantial wear (depth > 0.05 mm l
0.002 inch) we recommend that you have the
parts replaced or reworked
Alternative:
send the rolling head to LMT Fette for
inspection!
10.3 Wear parts
The following parts are main wear parts:
■ Washer (ET-15)
7
■ Spindels (ET-3)
■ Pinion (ET-8)
■ Gears (ET-10), (ET-11), (ET-12)
■ Bushing (ET-13)
It is recommended that you keep a supply of these parts.
7
For part numbers with the addition “SP” see the spare parts list Figure 24 on page 48.
