SW500 Wired Scale Systems, Users
Rev E,October, 2016
Page 22 of 36
Special key combinations
Press the ZERO and PRINT keys simultaneously to reach the following menu.
1. SWITCH lb/kg
2. READ ONLY (OFF/ON)
3. HUB MODE (OFF/ON)
(HIT ACUTAL TO EXIT)
Switch LB/KG
To switch from pounds units (lb) to kilograms (kg), the user can press a
To toggle lb/kg press “1” to toggle lb / kg.
Read Only Mode
If using multiple indicators all indicators except for the one being used as
the master indicator must be set to “READ ONLY”. Press the “2” to toggle
between Yes and No or ACTUAL to exit this screen.
Hub Mode
Press “3” to enter the Hub Mode options. See the “Quick Start (Hub
Mode)” section for further instructions on how to configure the system.
Change display format
To change the display format (this is first screen shown at power-up),
press the 1 and 0 keys simultaneously. The following screen should be
displayed:
1:OVAL 5:DRAG/RALLY
2:CUP/NW 6:WHT+%
3:ROAD RACE 7: TOTAL
4:DIRT TRK 8: TOTAL + 4
Press the number for the desired corresponding display format.
Lock Display Format
This feature allows for a specific display format (as shown in section
“Automotive Displays” or “Kart Displays”) to be shown immediately after
power-up. This means the display format selection menu (as shown on
page 8) will not be displayed after power-up. To activate this feature, go
to the desired display format and simultaneously press the ‘RF’, ‘3’, and
‘CLEAR’ keys. The message “DISPLAY CHOICE SAVED” will be
displayed for a second. Turn the indicator off and back on. The indicator
