SW500 Wired Scale Systems, Users
Rev E,October, 2016
Page 35 of 36
Error messages
Pad status error messages (these will display in place of a particular pad’s weight)
OFF
No communication from the selected pad. Ensure the pad is
turned on (the pad LED will blink when the pad is working
properly). If the LED does not turn on at all, check the batteries
in the pad.
LOST
Communication has been lost with a pad that was previously
communicating. Ensure that the pad wasn’t inadvertently turned
off and the battery condition.
EEPROM
Contact Intercomp service department for assistance.
BATT
Pad low battery. BATT will blink along with the weight applied to
the affected pad.
CAP
The pad is overcapacity or there is a load cell connection error.
Reduce the load to the pad and/or zero the pad. If the message
persists, there may be a load cell or load cell wiring failure.
UNITS
The pad is set to a different unit (lb / kg) than the indicator. See
“Switch lb/kg”.
GRAD
The pad is set to a different grad size (car / kart) than the
indicator.
Indicator status error messages
LOW DISPLAY
BATTERY
Indicator battery is running low. This message will blink on the
display. Replace batteries if using alkaline or recharge batteries
if using rechargeable batteries.
EEPROM ERROR
ENTER CODE: 00
EEPROM check fail. Contact Intercomp service department for
assistance.
HUB
COMPENSATION
ENABLED!
This is not an error, but a notice that your indicator has hub
mode compensations active. If you are not using a hub plate
system, you should disable hub mode by pressing
ZERO+PRINT together followed by “3”. Then press “1” to
switch HUB MODE from “ON” to “OFF”.
