Operation
18 www.loepfe.com
WeftMaster CUT-iT
4.3.2 Switching the device off
Cannot be used as emergency power off button.
n Even though the WeftMaster CUT-iT device is switched off:
– The emergency relay (output relay) is active.
– The weaving machine is not stopped.
– Current remains present in the device.
ü Device connected to power supply.
1.
Press for 3 seconds.
ð Display: «POWER OFF» (switched off)
ð Output current is switched off.
4.3.3 Putting the device into operation
ü Device connected to power supply.
1.
Press.
ð The following status messages are each displayed for 1 second during the Startup phase (see
Putting the device into operation [}16])
4.3.4 Current flow modes
Display (example)
n 1. Line
– «P:4» Program number is displayed.
– «Standby» Current flow mode is displayed.
n 2. Line
– «Current: 2.2 A» Output current is displayed.
