Logia LOWSB510PB - Specifications

33
CLEANING THE THERMO/HYGRO SENSOR
DISPLAY CONSOLE
2. Gently remove the rain collector.
3. Clean and remove any debris or insects.
4. Wait until the parts are fully dry, and then reinstall them, and return the rain collector to a locked
position.
1. Unscrew the 2 screws at the bottom of the sensor casing.
2. Gently pull out the shield.
3. Carefully remove any dirt or insects inside the sensor casing, making sure the inside sensors remain dry.
4. Clean the shield with water and remove any dirt or insects.
5. Once the parts are fully clean and dry, reinstall them and replace the screws.
SPECIFICATIONS
Interval (minutes) Number of Days Available for Data Logging
5 50
15 150
30 (default setting) 300
60 600
SPECIFICATIONS
DISPLAY CONSOLE
General Specifications
Dimensions (W x H x D) 4.6" x 7.5" x 1.2" (117 x 189 x 31mm)
Weight 1.06 lb. (480g) with batteries
Battery 6x AA size 1.5V batteries (alkaline recommended)
Weather data in console Barometric pressure, temperature, and humidity
Operating temperature range
23°F ~ 122°F (-5°C ~ 50°C)
PC Software Requirements
Wireless Sensor Communication Specifications
Time Function Specifications
Connection interface USB 2.0
Operation system
Windows XP, Windows Vista, Windows 7, Windows 10 or
latest version (32-bit / 64-bit)
Hard disk space 50 MB
Display resolution 1360 x 768 (1920 x 1080 recommended)
View or edit export data Microsoft Excel
®
or other similar software for PC
Weather Underground upload
requirements
Supported sensors
1 Wireless 5-in-1 weather outdoor sensor and up to 7 optional
wireless hygro-thermo outdoor sensors
RF frequency
868 MHz (EU or UK version), 915 MHz (US version),
917 MHz (AU version)
RF transmission range 492 ft (150m)
Time display HH: MM: SS
Hour format 12 hour or 24 hour
Date display DD / MM or MM / DD
Time synchronization method PC time (only available when connected to Windows
®
-based PC
running Weather Tool software)
Weekday languages EN / DE / FR / ES / IT / NL / RU
Barometer Display & Function Specifications
Note: The following details are listed as they are displayed or operate on the console.
Barometer units hPa, inHg, and mmHg
Measuring range
540 ~ 1100 hPa (relative setting range 930 ~ 1050 hPa)
Accuracy
(700 ~ 1100 hPa ± 5 hPa) / (540 ~ 696 hPa ± 8 hPa)
(20.67 ~ 32.48 inHg ± 0.15 inHg) / (15.95 ~ 20.55 inHg ± 0.24 inHg)
(525 ~ 825mmHg ± 3.8mmHg) / (405 ~ 522 mmHg ± 6 mmHg)
Typical at 77°F (25°C)
Resolution
1hPa / 0.01inHg / 0.1mmHg
Weather forecast
Sunny, Partly Cloudy, Cloudy, Rainy, Rainy / Stormy and Snowy
Display modes
Current
Memory modes
Historical data from last memory reset, daily Max / Min
Alarm
Pressure change alert
Resolution
0.1°F / 0.1°C T
Weather forecast
Sunny, Partly Cloudy, Cloudy, Rainy, Rainy / Stormy and Snowy
Display modes
Current
Memory modes
Historical data from last memory reset, daily Max / Min
Alarm
High / Low temperature alert
Indoor / Outdoor Temperature Display & Function Specifications
Note: The following details are listed as they are displayed or operate on the console.
Temperature unit
°C and °F
Display range
-40 ~ 176°F (-40 ~ 80°C)
Indoor Accuracy
>104°F ± 3.6°F (>40°C ± 2°C)
32°F ~ 104°F ± 1.8°F (0~40°C ± 1°C)
< 32°F ± 3.6°F (< 0°C ± 2°C)
Outdoor Accuracy
131°F ~ 140°F ± 0.9°F (55°C ~ 60°C ± 0.5°C)
50°F ~ 131°F ± 0.7°F (10°C ~ 55°C ± 0.4°C)
-4°F ~ 50°F ± 2.3°F (-20°C ~ 10°C ± 1.3°C)
-40°F ~ -4°F ± 3.4°F (-40°C ~ -20°C ± 1.9°C)
Resolution
1%
Display modes
Current
Memory modes
Historical data from last memory reset, daily Max / Min
Alarm
High / Low temperature alert
Indoor / Outdoor Humidity Display & Function Specifications
Note: The following details are listed as they are displayed or operate on the console.
Humidity unit
%
Display range
1 ~ 99%
Indoor Accuracy
20~39% RH ±8%RH @ 77°F (25°C)
40~70% RH ±5%RH @ 77°F (25°C)
71~90% RH ±8%RH @ 77°F (25°C)
Outdoor Accuracy
1 ~ 90% RH ± 2.5% RH @ 77°F (25°C)
90 ~ 99% RH ± 3.5% RH @ 77°F (25°C)
Display mode
Gust / Average
Memory modes
Historical Data from last memory reset, daily Max Gust/ Average
Alarm Hi Wind Speed Alert (Average / Gust)
Wind Speed & Direction Display and Function Specifications
Note: The following detail are listed as they are displayed or operate on the console.
Wind speed unit
mph, m/s, km/h and knots
Wind speed display range
0 ~ 112mph, 50m/s, 180km/h, 97knots
Resolution
0.1mph, 0.1m/s, 0.1km/h, 0.1knots
Speed accuracy
± 2.2 mph or ± 10% (whichever is greater)
Accuracy for rainfall
Range of rainfall
0 ~ 19999mm (0 ~ 787.3 in)
Resolution 0.254mm (0.01in)
Wind direction 16 direction or relative degree reading
Rain Display & Function Specifications
Note: The following details are listed as they are displayed or operate on the console.
Unit for rainfall
mm and in
± 7%
Memory modes
Rainfall display mode
Hourly / Daily / Weekly / Monthly / Total rainfall
Alarm High Hourly Rainfall Alert
Display modes
Current
Historical Data from last memory reset, daily Max
Beaufort scale
Wind Chill range
-40°F ~ 64.4°F (-40°C ~ 18°C), wind speed > 4 .8km/h
Heat index range 78.8°F ~ 122°F (26°C ~ 50 °C)
Weather Index Display & Function Specifications
Note: The following details are listed as they are displayed or operate on the console.
Weather index mode
Beaufort, Wind Chill, Heat Index and Dew point
0 ~ 12
Display modes
Memory modes
Historical Data from last memory reset, Daily Max / Min
Dew point range
-4°F ~ 140°F (-20°C ~ 60°C)
Current
- Internet connection
- Permit software to access internet (for firewall/anti-virus programs)
